Multi/Single Pass Digital Printing machine Printseek Series Turbo All-in-One
Product Details:
| Place of Origin: | China. Suzhou |
| Brand Name: | GeRun |
| Model Number: | G5-2818 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | RMB Meet to talk about |
| Payment Terms: | T/T |
Detail Information | |||
| Product Name: | Multi/Single Pass Printseek Series Turbo All-in-One G5-2818 | Printing Accuracy: | 600dpi*600dpi / 600dpi*1200dpi |
|---|---|---|---|
| Printing Speed: | 1800㎡/h（2.8mfull scan printing） 96 m/min（ single-pass mode Printing） | Max. Printing Width: | 600mm |
| Max. Feeding Width: | 2800mm | Media Thickness: | 2~20mm |
| No.s Of Print Head: | 18 | ||
| High Light: | Printseek Series Turbo All-in-One,Multi/Single Pass,the one focuses on effectiveness more | ||
Product Description
Multi/Single Pass Digital Printing machine Printseek Series Turbo All-in-One G5-2818
Gerun Turbo All-in-One, the one focuses on effectiveness more
Emphasize Single Pass：60cm Singlepass allowance less switch between single & multi pass
High Accuracy Switching Structure：Verticle main beam with high accuracy locating locking in switching unit
Super Wide & Deep Frame：Feeding width 2800mm for wide paper Deep platform for high speed stability
Strong Feeding：Front edge feeding 5 axis 5 servo More wheels for high loading
Multi/Single Pass Printseek Series Turbo All-in-One G5-2818
1. Long Life belt：Stengthened mateiral long serice life transmission belt
2. Powerful Function：Variable data, ERP connection, oneclick QR code scanning for system work
3. High Capacity Board：Control board based on singlepass High data capbility for high speed output
PARAMETERS
| Model | G5-2818 |
| Printing resolution | 600DPI*600DPI / 600DPI*1200DPI |
| Rip Software Rip | Maintop |
| Is customization supported? | IS |
| Picture Format | TIFF,JPG,PDF,PNG |
| FeedingMode | Auto servo Feeding |
| Print Head | EPSON Industrial ALL-MEMS Print Head |
| Working Environment | 18~30℃； humidity：50%~70% |
| Number of sprinkler heads | 18 |
| Operating System | Windows 7 or Later |
| Maximum print width | 600mm |
| Total Power | About 35KW |
| Media Thicknes | 1~20mm |
| Printer Size | 4803*4604*1960mm |
| Max. Feeding Width | Width 2.8 meters, unlimited length |
| Printer Weights | 4500kg |
| Max. Printing Speed | 1800㎡/h（2.8mfull scan printing） 96 m/min（ single-pass mode Printing） |
| Electric voltage | 380V±10% ；50~60HZ |
| There are two more | G5-2818 , G5-2816 |
